3g 4g flexible rotatable screen freestanding digital signage kiosk advertising machine with wifi

FOB Reference Price:Get Latest Price
$300.00 - $2,000.00 / Sets | 1 Set/Sets (Min. Order)
Panel Size:
Other 43"
Max Resolution:
1920 x 1080
Color:
16.7M
Lead Time:
Quantity(Sets) 1 - 500 >500
Est. Time(days) 15 Negotiable
Customization:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Graphic customization (Min. Order: 1 Sets)
ODM Product Design (Min. Order: 1 Sets) Less
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
N/A
Model Number:
CSXT-SR1
Type:
TFT
Application:
Indoor
Viewing Angle:
178° / 178°
Pixel Pitch:
0.282x 0.282
Contrast Ratio:
1200:1
Brightness:
300 nits
Response Time:
<8ms
Input Voltage:
100-240V
Warranty:
2 Years
After-sales Service Provided:
Video technical support, Free spare parts, Online support
Panel Size:
43"
Touch Screen:
W/O (can be customized)
Material:
Mild steel case + tempered glass
Optional Functions:
Camera, card reader, printer, scanner, keyboard, etc.
Available Size:
21.5" - 86"
Back Light:
led backlit
System:
Windows / Android Optional
Surround Frame Thickness:
29.7mm
Product Name:
freestanding digital signage kiosk
Panel Brand:
100% original A+ grade brand panel
Supply Ability
Supply Ability:
5000 Set/Sets per Month
Packaging & Delivery
Packaging Details
Thick plastic bag + fixed foam + thickened strong cardboard carton + wooden case(if needed)
Port
Shenzhen
Picture Example:
package-img
Lead Time :
Quantity(Sets) 1 - 500 >500
Est. Time(days) 15 To be negotiated
Hot Sales





Product Description

4g flexible rotatable screen freestanding digital signage kiosk advertising machine with wifi

CSXT-SR1-4343 Inch Rotating Screen Floor Standing Digital Signage
Quick ViewTouch ScreenW/O
Rotating Screen360 °
Frame Thickness29.7mm
SystemWindows/Android Optional
Available Size21.5"/ 27"/ 32"/ 43"/ 49"/ 55"/ 65"/ 75"/ 86" or customized
Materials3mm Aluminium alloy frame + 1.5mm cold-rolled  steel shell +  5mm  tempered glass display
Optional Functions3G/4G, camera, card reader(ID/NFC/IC card), printer, scanner(QR code/biomini), microwave inductor, microphone, keyboard or customized
ScreenPanel BrandOriginal brand new A+ grade brand panel
Panel Size43" (19" to 100" optional)
Display Size529.4mm(H)x941.2mm(V)
Viewing Angle89/89/89/89 (Typ.)(CR≥10)
Compatible HD Input480P/576P/720P/1080I/1080P
BacklitsLED
Display Ratio9:16
Rotating Degree360 °
Response Time<8ms
Field Rate60HZ
Color16.7M
Contrast Ratio1200:1
Resolution1080*1920
Brightness Nits300 cd/m2
Pixel Pitch0.282x 0.282
Theory Lifetime50000 hours
Transmittance92%
Hard Coating3H
Operation System PC VersionAndroid Version
Main BoardJ1900/Windows I3/Windows I5 optionalA20/RK3188/RK3288
Operating SystemWin7/win8/win10 optionalAndroid 4.4
(Android4.4.4/4.2.2/5.1.1/6.0.1/7.1.2 optional)
CPU J1900/I3-3217U/I5-3317UA20 Cortex-A7 dual-core
RK3188 Cortex-A9 quad-core
RK3288 Cortex-A17 quad-core
RAMDDR3 1G/2G/4G/8G/16G optionalDDR3 1G/2G(optional)
StorageSSD:64G/128G
NAND FLASH 500GB / 1T optional
NAND FLASH 4GB / 8G/32G optional
OSD LanguageEnglish or customizedEnglish or customized
Connection to NetworkRJ45/4G(optional)/WIFI (optional)RJ45/4G(optional)/WIFI
InterfaceUSB2.0*4, HDMI, VGA, RJ45, LAN,
4G/wifi(optional), audio, DC
USB2.0*2, SD card, HDMI, RJ45,
4G(optional),wifi, audio, DC
System Upgrade Support SD card upgrade
File FormatsVideo720P/1080P/H265/264/MPEG4/
AVI/WMV/3GP/MP4/MOV/FLV
Video720P/1080P/H263/264/MPEG4/
AVI/WMV/3GP/MP4/MOV/FLV
PictureJPG/JPEG/BMP/GIF/PNGPictureJPG/JPEG/BMP/GIF/PNG
MusicMP3/WMA/AAC/AC3/DTSMusicMP3/WMA/AAC/AC3/DTS
PowerPower130W
Power SupplyAC100-240V 50/60HZ
Working&Storage
Requirement
Working/Storage Temperature0-50°C/-20 - 60°C
Working/ Storage
Humidity
20%~80%/5% - 95%
BodyMaterialShell1.5mm cold-rolled steel with antirust paint
Frame3mm wire drawing aluminium alloy
Display5mm tempered glass
ColorWhite, black, silver, gold or customized
Size640*455*1925mm
Frame Thickness29.7mm
Other InstructionsPlay ModeSupport horizontal or vertical playing, automatically loop playing
Scrolling CaptionSupport over-long scrolling caption display
Auto On/OffAuto on/off according to the setting time
ResetWith reset switch, easy to operation
InputLVDS directly drive
Audio ModeHi-fi stereo audio
Speaker2 * 5W (8 ohm)
Video Reduction NoiseYes
Selectable Corner StyleRounded corner (right angle corner optional)
Optional Functions3G/4G, camera, card reader(ID/NFC/IC card), printer, scanner(QR code/biomini), microwave inductor,
microphone, keyboard or customized
AccessoriesPower cable*1 + keys*2 + warranty card * 1
PackingThick plastic bag + fixed foam + thickened strong cardboard carton + wooden case(if needed)
Product Detail



Packing







Factory Details





Our Certificates



Our Advantages
  • 1. Direct factory - None middle man, you can get bottom price and quicker response.
  • 2. OEM and ODM service - customized exterior designs, functions, sizes( 7”- 100”), colors(silver, gold, white, black, etc.) and logo are welcome.
  • 3. Quick response - all inquiries will be replied within 1 day by our sales.
  • 4. Promotional activity every month - 4% to 15% off for the activity models.
  • 5. Original brand panel - Promise using original 100% A+ brand panels
  • 6. Quick delivery - within 15 days
  • 7. Worry-free quality assurance - 3 times full inspection (by our production QC, the 3rd party QC and our QC experts with 8 years experience) before shipment to ensure “0 defective rate”
  • 8. 2 years warranty - We’ll also support clients for the maintenance even after the warranty runs out.
  • 9. Trust of customers - 96% of customers who have worked with us once have maintained long term cooperation.
Quality Assurance
  • Step 1.  100% inspection for all incoming materials by our IQC department, if the deficient rate is over our standard 2%, we will return the defective materials to our suppliers for rework, if less than 2%, we will change the defective parts by new qualified materials.
  • Step 2.  Before on-line production, all the appearance and functions of the boards must be 100% checked by our QC department.
  • Step 3.  Semi-finished goods must be 100% inspected by our QC department, if any defective part, we will repair it and then return it to the production line again.
  • Step 4.  IPQC(Input process quality control) must patrol inspecting during production process.
  • Step 5.  Completed sets must be 100% checked by the QC department, after that, all the goods start 24 hours aging testing
  • Step 6.  After aging testing, QC department will 100% check all goods again and then start packing.
  • Step 7.  After packing, QA department will start sampling inspection, then we will inform customers to arrange the inspection date of the goods.
